NUP2201MR6, SZNUP2201MR6
APPLICATIONS INFORMATION
The NUP2201MR6 is a low capacitance TVS diode array
designed to protect sensitive electronics such as
communications systems, computers, and computer
peripherals against damage due to ESD events or transient
overvoltage conditions. Because of its low capacitance, it
Option 2
Protection of two data lines with bias and power supply
isolation resistor.
I/O 1
can be used on high speed I/O data lines. The integrated
design of the NUP2201MR6 offers surge rated, low
I/O 2
V CC
capacitance steering diodes and a TVS diode integrated in a
single package (TSOP ? 6). If a transient condition occurs,
the steering diodes will drive the transient to the positive rail
of the power supply or to ground. The TVS device protects
the power line against overvoltage conditions to avoid
damage to the power supply and any downstream
1
2
3
6
5
4
10 k
components.
NUP2201MR6 Configuration Options
The NUP2201MR6 is able to protect two data lines
against transient overvoltage conditions by driving them to
a fixed reference point for clamping purposes. The steering
diodes will be forward biased whenever the voltage on the
protected line exceeds the reference voltage (Vf or V CC +
Vf). The diodes will force the transient current to bypass the
sensitive circuit.
Data lines are connected at pins 1 and 6. The negative
reference is connected at pin 2. This pin must be connected
directly to ground by using a ground plane to minimize the
The NUP2201MR6 can be isolated from the power supply
by connecting a series resistor between pin 5 and V CC . A
10 k W resistor is recommended for this application. This
will maintain bias on the internal TVS and steering diodes,
reducing their capacitance.
Option 3
Protection of two data lines using the internal TVS diode
as reference.
I/O 1
I/O 2
PCB’s ground inductance. It is very important to reduce the
PCB trace lengths as much as possible to minimize parasitic
1
6
inductance.
Option 1
Protection of two data lines and the power supply using
V CC as reference.
2
3
5
4
NC
I/O 1
I/O 2
In applications lacking a positive supply reference or
those cases in which a fully isolated power supply is
required, the internal TVS can be used as the reference. For
1
6
these applications, pin 5 is not connected. In this
configuration, the steering diodes will conduct whenever the
2
3
5
4
V CC
voltage on the protected line exceeds the working voltage of
the TVS plus one diode drop (Vc = Vf + V TVS ).
ESD Protection of Power Supply Lines
When using diodes for data line protection, referencing to
For this configuration, connect pin 5 directly to the
positive supply rail (V CC ), the data lines are referenced to
the supply voltage. The internal TVS diode prevents
overvoltage on the supply rail. Biasing of the steering diodes
a supply rail provides advantages. Biasing the diodes
reduces their capacitance and minimizes signal distortion.
Implementing this topology with discrete devices does have
disadvantages. This configuration is shown below:
reduces their capacitance.
http://onsemi.com
5
